CRAWLER CRANE MARCHETTI CW 70.42

70 tons

MARCHETTI CW 70.42 L SHERPA crawler crane. Equipped with Perkins Diesel Engine Euro 5. Max load 70 tons. Max outreach 42 mt. Max height 45 mt, with JIB 58.5 mt. Rotation 360°. Winch 220 meters with 18 mm rope diameter, 9 tons counterweight. Crawlers are operated by variable displacement hydraulic motors and epicycloidal reducers with multiple discs brake in oil bat. With telescoping beam outriggers and vertical jacks with independent movements controlled from the crane cabin. Extensible crawler.

Key features

 DOWNLOAD
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [1]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [2]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [3]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [4]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [5]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [6]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [7]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [8]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [9]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [10]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [11]

Delivery

worldwide delivery: available

delivery time: 90 days + shipping

payment terms: 30% at order - 70% before shipping

CRAWLER CRANE MARCHETTI CW 70.42

70 tons

MARCHETTI CW 70.42 L SHERPA crawler crane. Equipped with Perkins Diesel Engine Euro 5. Max load 70 tons. Max outreach 42 mt. Max height 45 mt, with JIB 58.5 mt. Rotation 360°. Winch 220 meters with 18 mm rope diameter, 9 tons counterweight. Crawlers are operated by variable displacement hydraulic motors and epicycloidal reducers with multiple discs brake in oil bat. With telescoping beam outriggers and vertical jacks with independent movements controlled from the crane cabin. Extensible crawler.

Key features

 DOWNLOAD

Page published: 2024-05-30

crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [1]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [2]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [3]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [4]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [5]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [6]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [7]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [8]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [9]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [10]
crawler-crane marchetti cw-70.42 photos
marchetti cw 70.42 70 tons crawler-crane photo nr [11]

e.u. guarantee

E.U. legislation provides a Free of charge, 2 years guarantee for private person, and 1 year for company (legal guarantee) on faulty goods, for all products we sell, this is important because it is a guarantee that the goods sold by us are covered by European protection. All goods we sell are invoiced by Silcom North UAB, a company registered in Vilnius, Lithuania. Every product we send is checked before departure, but in case there are any problems, the customer is required to notify us as soon as possible, and must not use the product until our withdrawal. In case the customer needs a repair, we are always available to assist him, even after the warranty expires.

why choose us

Because for 50 years we have been dealing with industrial supplies, we have seen technology evolve and needs change. Because we are used to working with customers from all over the world, because we believe that after-sales service is as important as the technical preparation of our staff. We like to listen to requests, and propose the best solutions.

features

crawler-crane marchetti cw-70.42mg-70.4mtk-1005 photos

Hook block

50 tons hook block with five pulleys

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42 photos

Limiting system

Lifting hoist limit switch, safety and pressure valves, emergency stop device and electronic moment limiter device

crawler-crane marchetti cw-25.35cw-45.32cw-55.40cw-65.40cw-70.42 photos

Hydraulic system

load sensing hydraulic system with variable displacement piston pump and power adjustment for crane and crawlers operation, up to 4 contemporary manoeuvres, with oil cooler

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42 photos

Undercarriage

torsion resistant frame with extendable crawler carriers and locking rods. Standard 800mm triple grouser shoes

crawler-crane marchetti cw-70.42 photos

Boom

high resistance steel telescoping boom with one base section, one indipendent telescopic section, three syncronized telescopic sections, from 11.2 to 42 meters extension

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42mg-70.4mg-60.3mtk-40mtk-60mtk-1006mtk-1005mtk-180 photos

Hoist gear

Piston hydraulic motor with epicyclical reducer and automatic multiple disk brake, grooved drum

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42 photos

Board computer

Board computer with machine control and Electronic Limiting Device (LMI) operated in Can-Bus, crawler track monitoring

crawler-crane marchetti cw-25.35cw-45.32cw-55.40cw-65.40cw-70.42mtk-40mtk-60mtk-1006mtk-1005mtk-180 photos

Slewing system

continuous 360° rotation achieved by one orbital hydraulic motor with epicyclic reducer and automatic multiple discs brake in oil bath

crawler-crane marchetti cw-25.35cw-45.32cw-55.40cw-65.40cw-70.42 photos

Electric system

24 VDC. two 120Ah batteries with CAN-BUS data system

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42 photos

Safety devices

3-color warning signal light positioned on the front. Buzzer. Rotating light. Fire extinguisher.

crawler-crane marchetti cw-70.42 photos

Counterweight

one lead element ballast, 9 tons, pinned to the superstructure

crawler-crane marchetti cw-25.35cw-25.35-hycw-45.32cw-55.40cw-65.40cw-70.42mtk-40mtk-60mtk-1006mtk-1005mtk-180 photos

Boom elevation

differential hydraulic cylinder equipped with piloted load control valve

crawler-crane marchetti cw-70.42 photos

Outriggers

4 hidraullicaly telescoping bean outriggers with independent movements controlled from the crane cabin
